Unistrut P4520

Abhay Steels Supplies and Manufactures high-quality Unistrut P4520 Channels in India

Are you trying to find a trustworthy Unistrut P4520 supplier? Abhay Steels supplies high-quality channel sections designed for robust, adaptable support in industrial, mechanical, and electrical installations. When dependable load performance and simple assembly are important, P4520 profile is utilized for mounting, framing, and structural support.

Unistrut systems are profitable because they reduce fabrication time, make installation easier, and enable quick on-site changes. P4520 is a wise choice if your project requires a useful support solution that strikes a balance between strength, versatility, and efficiency.

The Reasons for Selecting Unistrut P4520

P4520 is designed for tasks that require modular support. By combining it with appropriate fittings, brackets, clamps, and fasteners, you may construct unique frames without the need for intricate construction or heavy welding.

Abhay Steels' quality

The goal at Abhay Steels is to provide industrial products that satisfy project requirements and endure in harsh environments. When the channel enters support structures and load-bearing assemblies, buyers seek consistency, accurate dimensions, and a reliable finish.

Unistrut P4520 Specification

Product	Unistrut P4520
Standard Length	Up to 12 meters
Width	1-5/8 inches (41.3 mm)
Height	13/16 inches (20.6 mm)
Wall Thickness	12 Gauge (0.105″ / 2.7 mm)
Allowable Moment	1,615 in-lbs (183 N·m)
Weight	131 lbs/100 ft (190 kg/100 m)
Finishes	Plain (PL), Stainless Steel (SS), Galvanized (Pre-galvanized / Hot-dip), Aluminum (EA)
Material	Stainless Steel
Grades	Type 304 (SS), Type 316 (ST)
Standard	ASTM A240

SP4520 - Beam Loading (Imperial)

Span In	Max Allowable Uniform Load Lbs	Defl. at Uniform Load In	Uniform Loading at Deflection
Span In	Max Allowable Uniform Load Lbs	Defl. at Uniform Load In	Span/180 Lbs	Span/240 Lbs	Span/360 Lbs
24	540	0.11	540	510	340
36	360	0.24	300	220	150
48	270	0.43	170	130	80
60	220	0.68	110	80	50
72	180	0.96	70	60	40
84	150	1.27	60	40	30
96	130	1.65	40	30	20
108	120	2.16	30	20	20
120	110	2.72	30	20	NR
144	90	3.84	20	NR	NR

P4520 - Beam Loading (Metric)

Span MM	Max Allowable Uniform Load kN	Defl. at Uniform Load MM	Uniform Loading at Deflection
Span MM	Max Allowable Uniform Load kN	Defl. at Uniform Load MM	Span/180 kN	Span/240 kN	Span/360 kN
600	2.5	2.6	2.5	2.4	1.6
750	2.0	4.1	2.0	1.5	1.0
1000	1.5	7.3	1.1	0.9	0.6
1250	1.2	11.3	0.7	0.5	0.4
1500	1.0	16.5	0.5	0.4	0.3
1750	0.9	22.6	0.4	0.3	0.2
2000	0.7	28.4	0.3	0.2	0.1
2500	0.6	45.0	0.2	0.1	0.1
3000	0.5	65.8	0.1	0.1	NR
3500	0.4	85.5	0.1	0.1	NR

P4520 - Column Loading (Imperial)

Unbraced Height In	Maximum Allowable Load at Slot Face Lbs	Maximum Column Load Applied at C.G.
Unbraced Height In	Maximum Allowable Load at Slot Face Lbs	K = 0.65 Lbs	K = 0.80 Lbs	K =1.0 Lbs	K = 1.2 Lbs
24	2,250	7,480	6,800	5,820	4,810
36	1,980	5,950	4,810	3,380	2,350
48	1,580	4,310	2,970	1,900	**
60	1,210	2,880	1,900	**	**
72	950	2,000	**	**	**

P4520 - Column Loading (Metric)

Unbraced Height kN	Maximum Allowable Load at Slot Face MM	Maximum Column Load Applied at C.G.
Unbraced Height kN	Maximum Allowable Load at Slot Face MM	K = 0.65 kN	K = 0.80 kN	K =1.0 kN	K = 1.2 kN
600	10.3	34.1	31.1	26.8	22.2
750	9.7	30.9	26.8	21.1	15.8
1000	8.5	24.9	19.3	12.8	8.9
1250	6.9	18.9	12.8	8.2	**
1500	5.6	13.5	8.9	**	**
1750	4.6	9.9	6.5	**	**

P4520 - Elements of Section (Imperial)

Parameter	P4400
Area of Section	0.384	In²
Axis 1-1
Moment of Inertia (I)	0.031	In⁴
Section Modulus (S)	0.064	In³
Radius of Gyration (r)	0.283	In
Axis 2-2
Moment of Inertia (I)	0.138	In⁴
Section Modulus (S)	0.170	In³
Radius of Gyration (r)	0.599	In

P4520 - Elements of Section (Metric)

Parameter	P4520
Area of Section	2.48	cm²
Axis 1-1
Moment of Inertia (I)	1.29	cm⁴
Section Modulus (S)	1.05	cm³
Radius of Gyration (r)	0.72	cm
Axis 2-2
Moment of Inertia (I)	5.74	cm⁴
Section Modulus (S)	2.79	cm³
Radius of Gyration (r)	1.52	cm

Principal advantages

Robust, long-lasting support for industrial applications
Simple to install and adjust
Suitable for mechanical, plumbing, HVAC, and electrical systems
reduces installation complexity and labor time
works for both new construction and retrofit projects.

Uses

P4520 is frequently utilized in:

Systems for cable support and cable trays
Support for pipes and conduits
Framing for HVAC equipment
Mounting of machinery and equipment
Support for plant structure and utility
Modular industrial frames, bracing, and racking

FAQS

What is the purpose of the Unistrut P4520?

Assist with suspension, mounting, and framing in industrial, mechanical, electrical, and HVAC systems.

Why should I purchase the Unistrut P4520 from Abhay Steels?

For consumers who require high-quality channel sections for their projects, we offer dependable sourcing, industrial supply knowledge, and genuine support.

Does Unistrut P4520 work well with modular buildings?

Indeed. Its ease of assembly, adjustment, and expansion frequently leads to its use in modular support systems.

Would it be possible to utilize Unistrut P4520 for cable support?

Indeed. It is frequently utilized for electrical support tasks, such as cable tray support.
