Unistrut P1100

Abhay Steels Manufactures and Distributes Unistrut P1100 Channel in India

Unistrut P1100 of the most robust and versatile profiles available for bolt-together framing is the Unistrut P1100. At Abhay Steels, we provide authentic P1100 channels that satisfy global requirements without sacrificing quality.

Unistrut P1100: What is it?

P1100 is a solid, 12-gauge (2.5 mm thick), 1-5/8 x 1-5/8 (41 x 41 mm) metal framing channel. P1100 is particularly robust for direct mounting and welding because it has a continuous solid profile without return lips, in contrast to the back-to-back P1000 series. You may achieve complete adjustability without drilling or welding on-site thanks to its continuous slot with inturned edges, which accepts conventional Unistrut spring nuts and fittings.

Consider it the heavy-lifting relative of the typical strut profiles. It is constructed from high-quality mild steel that complies with IS 5986 and ASTM A1011, and it is available in finishes appropriate for any setting.

We always have the P1100 in stock in a variety of finishes, so you never have to compromise on corrosion resistance:

Pre-Galvanized (PG) steel has an inexpensive, silvery finish and is suitable for indoor.
For outdoor and coastal work, hot-dip galvanized (HDG) offers better rust resistance.
Black or plain steel is suitable for painting or powder coating following manufacturing.

Unistrut P1100 Specification

Product	Unistrut P1100
Standard Length	Up to 12 meters
Width	1-5/8 inches (41 mm)
Height	1-5/8 inches (41 mm)
Wall Thickness	14 Gauge (0.075″ / 1.9 mm)
Allowable Moment	4,060 in-lbs (460 N·m)
Weight	142 lbs/100 ft (211 kg/100 m)
Material	Stainless Steel
Grades	Type 304, Type 316
Standard	ASTM A240

P1100 - Beam Loading (Imperial)

Span In	Max Allowable Uniform Load Lbs	Defl. at Uniform Load In	Uniform Loading at Deflection
Span In	Max Allowable Uniform Load Lbs	Defl. at Uniform Load In	Span/180 Lbs	Span/240 Lbs	Span/360 Lbs
24	1,350	0.06	1,350	1,350	1,350
36	900	0.13	900	900	700
48	680	0.23	680	590	400
60	540	0.36	510	380	250
72	450	0.51	350	260	180
84	390	0.70	260	190	130
96	340	0.92	200	150	100
108	300	1.15	160	120	80
120	270	1.42	130	90	60
144	230	2.09	90	70	40
168	190	2.75	60	50	30
192	170	3.67	50	40	NR
216	150	4.61	40	30	NR
240	140	5.90	30	NR	NR

P1100 - Beam Loading (Metric)

Span MM	Max Allowable Uniform Load kN	Defl. at Uniform Load MM	Uniform Loading at Deflection
Span MM	Max Allowable Uniform Load kN	Defl. at Uniform Load MM	Span/180 kN	Span/240 kN	Span/360 kN
600	6.1	1	6.1	6.1	6.1
750	4.9	2	4.9	4.9	4.7
1,000	3.7	4	3.7	3.7	2.6
1,250	2.9	6	2.9	2.5	1.7
1,500	2.4	9	2.3	1.7	1.2
1,750	2.1	12	1.7	1.3	0.8
2,000	1.8	15	1.3	1.0	0.7
2,500	1.5	24	0.8	0.6	0.4
3,000	1.2	36	0.6	0.4	0.3
3,500	1.1	49	0.4	0.3	0.2
4,000	0.9	64	0.3	0.3	0.2
4,500	0.8	77	0.3	0.2	0.1
5,000	0.8	100	0.2	0.2	NR
6,000	0.6	143	0.1	NR	NR

P1100 - Column Loading (Imperial)

Unbraced Height In	Maxiumum Allowable Load at Slot Face Lbs	Maximum Column Load Applied at C.G.
Unbraced Height In	Maxiumum Allowable Load at Slot Face Lbs	K = 0.65 Lbs	K = 0.80 Lbs	K = 1.0 Lbs	K = 1.2 Lbs
24	2,800	8,040	7,330	6,360	5,430
36	2,410	6,480	5,430	4,190	3,210
48	1,940	4,990	3,830	2,760	2,160
60	1,550	3,740	2,760	2,050	1,640
72	1,290	2,860	2,160	1,640	1,320
84	1,100	2,310	1,780	1,370	1,110
96	950	1,950	1,520	1,180	950
108	840	1,690	1,320	1,030	**
120	760	1,490	1,180	**	**
144	630	1,210	950	**	**

P1100 - Column Loading (Metric)

Unbraced Height (mm)	Maximum Allowable Load at Slot Face (kN)	Maximum Column Load Applied at C.G.
Unbraced Height (mm)	Maximum Allowable Load at Slot Face (kN)	K = 0.65 (kN)	K = 0.80 (kN)	K = 1.0 (kN)	K = 1.2 (kN)
600	12.5	35.9	32.9	28.6	24.5
750	11.8	32.6	28.6	23.5	19.0
1,000	10.1	26.9	22.0	16.4	12.5
1,250	8.5	21.6	16.4	11.8	9.3
1,500	7.0	17.0	12.5	9.0	7.4
1,750	6.0	13.5	10.1	7.7	6.2
2,000	5.2	11.2	8.6	6.3	4.7
2,250	4.6	9.6	7.4	5.3	4.4
2,500	4.1	8.4	6.6	5.1	**
2,750	3.7	7.5	5.9	4.5	**

P1100 - Elements of Section (Imperial)

Parameter	1100
Area of Section	0.418	In²
Axis 1-1
Moment of Inertia (I)	0.145	In⁴
Section Modulus (S)	0.162	In³
Radius of Gyration (r)	0.589	In
Axis 2-2
Moment of Inertia (I)	0.176	In⁴
Section Modulus (S)	0.217	In³
Radius of Gyration (r)	0.650	In

P1100 - Elements of Section (Metric)

Parameter	P1100
Area of Section	2.69	cm²
Axis 1-1
Moment of Inertia (I)	6.03	cm⁴
Section Modulus (S)	2.65	cm³
Radius of Gyration (r)	1.50	cm
Axis 2-2
Moment of Inertia (I)	7.34	cm⁴
Section Modulus (S)	3.56	cm³
Radius of Gyration (r)	1.65	cm

Uses in Which P1100 Excels

Solid purlins and module rails for solar PV mounting in high-wind areas
Conduit racks and electrical cable trays: stiff cross members for heavily loaded trays
Strong beams and columns for material handling on industrial mezzanine floors and racks
Vibration-resistant mounting frames for rail and transportation projects

FAQ

What is a Unistrut P1100 channel's actual load capacity?

The type of loading, support conditions, and beam span all have a role. A one-meter-long, simply supported P1100 can support a load of roughly 200–250 kg, evenly distributed within its safe operating range. Refer to the official Unistrut load tables or contact our technical staff for project-specific figures.

Is it possible to utilize the P1100 back-to-back like the P1000?

Not at all. The P1100 is not intended to be welded back-to-back since it is a solid channel. The P1000 (12 gauge) or P2000 (14 gauge) profiles are ideal for back-to-back setups. When you need a single heavy-gauge component for embedment, clamping, or direct welding, use the P1100.

Is it possible to use regular Unistrut spring nuts and brackets with the P1100?

Indeed. Standard Unistrut M8, M10, and M12 channel nuts, spring nuts, and all corresponding brackets, clamps, and angle fittings are compatible with the slot dimensions (22.2 mm x 12.7 mm).

What lengths are available for P1100?

We have regular 3-meter (10-foot) lengths in stock, and for large orders, we will cut to precise millimeter lengths at no additional cost. Additionally, custom profile fabrication and hole-punching are offered.

Is it possible to obtain P1100 in stainless steel for a solar project along the coast?

Indeed. For corrosive environments, including offshore platforms, chemical facilities, and coastal solar farms, we frequently provide P1100 in SS304 and SS316. These are long-lasting without corrosion.
