409 Stainless Steel Sheets
Jindal 1.4512/409 Stainless Steel Sheets
Product Brochure
Steel Grade | SS409 L |
Material | Stainless Steel |
Usage/Application | Industry |
Thickness | 0.5 to 20 mm |
Width Range | 1000 to 1250 mm |
Length Range | 500 to 6000 mm |
We stock wide range of different size quantities of "Jindal Stainless Ltd" brand Stainless steel 409 sheets & 1.4512 sheet in various finishes like BA Finish 409 Sheet, 2B Finish 1.4512 sheets, Matt Finish 1.4512 stainless sheet, Mirror Finish 409 stainless sheet, Matte Finish, No. 4 Finish, BA + Matte PVC Finish stainless steel sheets. We have stock of 200 to 300MT in stainless Steel sheets for 409 / 1.4512 of "Jindal Brand". You can check " authorised dealer certificate" for stainless steel sheets from Jindal in the left
1.4512 Stainless Steel Sheets
Product Brochure
Thickness | 0.5 to 20 mm |
Steel Grade | SS409 |
Material | Stainless Steel |
Usage/Application | Industry |
Width Range | 1000 to 1250 mm |
Length Range | 500 to 6000 mm |
Abhay steel is the largest dealer, exporter, fabricator, stockiest and importer of the wide ranges and quality of Stainless Steel 409 Sheets/ Plates. These sheets and plates are sold all around the world. They are superb in the quality and they are also available in the customized and standard sizes to the clients. We are producing a large variety of plates and sheets. That is available in different specifications such as dimensions, size, shape, surface finish, end finish, hardness, and appropriate thickness. The same is supplied to the customers with the cut-made specifications as per their expectations.
The stainless steel 409 is the chromium, titanium settled, ferritic stainless steel which is universally useful. Alloy is usually useful and essential for applications like manufacturing of car fumes framework. They develop a latent surface which allows the stainless steel to maintain their consumption resistance. This is due to the contents of chromium which are present in the alloy. It takes over the great lifted temperature of the environment that helps in the erosion resistance. The alloy also has great formability. This alloy is contrasted with the carbon steel which gives it strength to be protected at the elevated temperatures. The alloy is widely used at the places where there is a need to use the auxiliary quality and erosion resistance ability.
Attributes of the steel sheets/plates-
Various attributes make the product widely used among all the industries. The features of the steel plates that our products have-
- High-temperature bearing capacity
- Durability
- Resistance to corrosion and pitting
- High tensile strength
Stainless Steel 409
Minimum Order Quantity: 2500 Kg
Product Brochure
Grade | 409 / 409M |
Thickness | 1MM |
Type | Stainless Steel |
Usage/Application | Automobile Industry |
Material Grade | 409 |
Material | Stainless Steel |
Shape | Coil |
Size | 1250 x 1MM |
Weight | 2500 to 3000 Kg |
Good cold workability similar to that of low alloy steels.
Good corrosion resistance in natural atmospheres and in contact with moderately corrosive media.
Good oxidation resistance up to 800 0C.
Good weldability
Additional Information:
- Production Capacity: 2000 Ton
- Delivery Time: Ready Stock
- Packaging Details: Wooden Coil packing
409 Stainless Steel Sheets
Material | Stainless Steel |
Usage/Application | Industry |
Thickness | 0.5 upto 5 mm |
Steel Grade | SS409 |
Surface Treatment | Cold Rolled |
Width | 1000 to 1250 mm |
Length | 500 to 6000 mm |
Stainless Steel Sheets 409
Material Grade | SS409 |
Usage/Application | Industry |
Thickness | 0.5 upto 5 mm |
Application | Oil & Gas Industry |
Width | 1000 to 1250 mm |
Length | 500 to 6000 mm |
JIS SUS 409 Stainless Steel Sheets
Usage/Application | Industry |
Thickness | 0.5 to 20 mm |
Steel Grade | SS409 |
Material | Stainless Steel |
Width Range | 1000 to 1250 mm |
Length Range | 500 to 6000 mm |
BS 409S17 Stainless Steel Sheets
Steel Grade | SS409 |
Material | Stainless Steel |
Usage/Application | Industry |
Thickness | 0.5 to 20 mm |
Width Range | 1000 to 1250 mm |
Length Range | 500 to 6000 mm |
JIS SUS 409L Stainless Steel Sheets
Material | Stainless Steel |
Usage/Application | Industry |
Thickness | 0.5 to 20 mm |
Steel Grade | SS409 L |
Width Range | 1000 to 1250 mm |
Length Range | 500 to 6000 mm |
UNS S40900 Stainless Steel Sheets
Steel Grade | SS409 |
Material | Stainless Steel |
Usage/Application | Industry |
Thickness | 0.5 to 20 mm |
Width Range | 1000 to 1250 mm |
Length Range | 500 to 6000 mm |
Stainless Steel Sheet 409L
Minimum Order Quantity: 100 Kilogram
Usage/Application | Industry |
Thickness | 0.5 upto 5 mm |
Steel Grade | SS409 L |
Material | Stainless Steel |
Surface Treatment | Hot Rolled, Cold Rolled |
Sheet Size | 1250x2500,1500x3000 Feet |
Material Grade | 409L |
Width | 1000 to 1250 mm |
Length | 500 to 6000 mm |
Grade 409 steels are also available in highly stabilized forms, such as grades S40930, S40920 and S40910. The stability of these grades is provided by the presence of niobium, titanium, or both, in the composition of steels.
Additional Information:
- Pay Mode Terms: T/T (Bank Transfer)
- Delivery Time: immediate
Stainless Steel Sheet 409
Steel Grade | SS 409 |
Surface Treatment | Cold Rolled |
Material | Stainless Steel |
Usage/Application | Industry |
Width | 1000 to 1250 mm |
Length | 500 to 6000 mm |
Stainless Steel 409 Sheets
Thickness | 0-1 mm, 1-2 mm, 2-3 mm, 3-4 mm, 4-5 mm, 5mm |
Steel Grade | SS 409 |
Usage/Application | Industry |
Surface Treatment | Hot Rolled |
Elongation | 20% |
Ultimate Tensile Strength | 55 min ksi |
Yield Strength | 0.2% 25 min |
Aesteiron Steels Pvt Ltd is one of the leading manufacturers & suppliers of SS 409 Sheets.
SS 409 Chemical Composition
Carbon | 0.08 |
Silicom | 1.00 |
Manganese | 1.00 |
Phosphorus | 0.045 |
Sulfur | 0.045 |
Chromium | 10.5-11.75 |
Nickel | 0.50 |
Others | Ti 6xC/0.75 |
Equivalent grades
AISI 409
DIN X6CrTi12
WNR 1.4512
AFNOR Z6CT12
JIS SUH409
UNI X6CrTi12
BSI 409S19
Euronorm X5CrTi12
Applications
Transformer cases
Automotive exhaust tubing
Farm equipments
Catalytic converter systems
Structural Support & Hangers
AISI 409 Stainless Steel Sheets
Product Brochure
Material | Stainless Steel |
Usage/Application | Industry |
Thickness | 0.5 to 20 mm |
Steel Grade | SS409 |
Width Range | 1000 to 1250 mm |
Length Range | 500 to 6000 mm |
Abhay steel is the largest dealer, exporter, fabricator, stockiest and importer of the wide ranges and quality of Stainless Steel 409 Sheets/ Plates. These sheets and plates are sold all around the world. They are superb in the quality and they are also available in the customized and standard sizes to the clients. We are producing a large variety of plates and sheets. That is available in different specifications such as dimensions, size, shape, surface finish, end finish, hardness, and appropriate thickness. The same is supplied to the customers with the cut-made specifications as per their expectations.
The stainless steel 409 is the chromium, titanium settled, ferritic stainless steel which is universally useful. Alloy is usually useful and essential for applications like manufacturing of car fumes framework. They develop a latent surface which allows the stainless steel to maintain their consumption resistance. This is due to the contents of chromium which are present in the alloy. It takes over the great lifted temperature of the environment that helps in the erosion resistance. The alloy also has great formability. This alloy is contrasted with the carbon steel which gives it strength to be protected at the elevated temperatures. The alloy is widely used at the places where there is a need to use the auxiliary quality and erosion resistance ability.
Attributes of the steel sheets/plates-
Various attributes make the product widely used among all the industries. The features of the steel plates that our products have-
- High-temperature bearing capacity
- Durability
- Resistance to corrosion and pitting
- High tensile strength
Quality assurance and material testing-
The quality of the Stainless Steel 409 Sheets/ Plates is checked at every single step of the manufacturing process. This is done to manufacture a safe and secure product that satisfies the needs and wants of the clients. We manufacture the top-notch quality of the product. All the manufacturing norms are followed by the quality controllers in the development of the steel plates/sheets. And the ranges are also set up as per the national and international set of quality standards.
Apart from keeping an eye on the manufacturing of the product, quality checkers perform certain tests. These tests are performed after the product is manufactured so that no poor quality of the product is delivered to the well-esteemed clients. The quality tests which are performed -
- Hardness test
- Hydrostatic test
- Ultrasonic test
- Positive material identification
- Micro and macro test
Stainless Steel 409L Sheets
Minimum Order Quantity: 100 Kilogram
Product Brochure
Thickness | 0-1 mm |
Grade | 409 |
Steel Grade | SS409 L |
Material Grade | SS409 L |
Finish | 2B |
Material | Stainless Steel |
Usage/Application | Industry |
Certification | ISO |
Surface Treatment | Hot Rolled, Coated |
ABHAY STEELS is stockiest / supplier of SS 409L sheets / plates / coils . Stainless Steel (UNS S40900) is a stabilized ferritic stainless steel that provides improved oxidation and corrosion resistance compared to carbon steel. Ease of fabrication combined with its corrosion resistance and economy have significantly broadened its utilization in automotive exhaust and other non-automotive applications. ASTM A240 defines three (3) subcategories of Type 409 stainless steel; UNS S40910, UNS S40920, and UNS S40930. Each of these designations has a slightly different Ti or Nb stabilization requirement. Each of these compositions can be supplied as UNS S40900 unless the purchaser specifically identifies a specific composition. It is produced with enhanced formability characteristics known as "High Performance" or "Ultra Form" in the industry.
Additional Information:
- Packaging Details: PALLET
Stainless steel 430 no4pvc sheets
Product Brochure
Product Type | Stainless steel 430 sheets,coils |
